1 tab(s): please give me an IO count from this tag list
# IO TASK HOURS ESTIMATE
## Preview
![[IO_TASK_HOURS_ESTIMATE_page1.png]]
![[IO_TASK_HOURS_ESTIMATE_page2.png]]
---
<details><summary>Extracted Data (all tabs)</summary>
## please give me an IO count from this tag list
| CHECK MY TIME ESTIMATES BELOW (IN YELLOW) FOR ADDING AOIs, OIT OBJECTS, HISTORIAN, AND TESTING | | | | | | | | | | |
| --- | --- | --- | --- | --- | --- | --- | --- | --- | --- | --- |
| ALSO LET ME KNOW IF YOU THINK I'M MISSING A FUNCTION ETC | | | | | | | | | | |
| | | | | | | | | | | |
| | | | | | | | | | | |
| | | | | | | | | | | |
| PLC TIME ESTIMATE | | | DI | DO | AI | AO | ALM A | ALM D | PID | TOTALIZER |
| EST HRS | EST MIN | EQUIPMENT | 5 | 5 | 10 | 10 | 5 | 5 | 0 | 20 |
| 1.08 | 65 | AIT | 1 | | 1 | | 4 | 1 | 1 | |
| 0.42 | 25 | LS | 1 | | | | | 4 | | |
| 0.58 | 35 | LIT/PIT/DPIT/WIT | | | 1 | | 5 | | | |
| 0 | 0 | | | | | | | | | |
| 0.25 | 15 | FS/PS/DPS | 1 | | | | | 2 | | |
| 0.5 | 30 | FIT/TIT | | | 1 | | | | | 1 |
| 1.67 | 100 | FCV-MOV | 3 | | 1 | 1 | | 3 | 1 | 1 |
| 1 | 60 | CV-MOV | 3 | 2 | | | | 3 | | 1 |
| 1.58 | 95 | PRV-MOV | | 2 | 1 | 1 | | 3 | 1 | 1 |
| 0.42 | 25 | PRV-SOL | | 1 | | | | | | 1 |
| 2.33 | 140 | MT-1 VFD | 5 | 1 | 1 | 1 | 1 | 3 | 1 | 2 |
| 2.67 | 160 | MT-2 VFD SUB | 7 | 1 | 1 | 1 | 1 | 5 | 1 | 2 |
| 1 | 60 | MT-3 ATL | 4 | 1 | | | | 3 | | 1 |
| 1.42 | 85 | MT-4 ATL SUB | 7 | 1 | | | | 5 | | 1 |
| 1.25 | 75 | MT-5 ATL SUB EQ | 6 | 1 | | | | 4 | | 1 |
| 1.08 | 65 | MT-6 SS | 5 | 1 | | | | 3 | | 1 |
| 1.58 | 95 | MT-7 CHEM | 2 | 1 | 1 | 1 | 1 | 1 | 1 | 1 |
| 0.17 | 10 | HT | 1 | | | | | 1 | | |
| | | | | | | | | | | |
| TIME TO ADD AN AOI AND LINK IO FOR EACH IO / FUNCTION IS YELLOW HIGHLIGHT | | | | | | | | | | |
| CALCULATED TOTAL ESTIMATED TIME FOR EACH PIECE OF EQUIPMENT IS IN BLUE | | | | | | | | | | |
| | | | | | | | | | | |
| IGNITION OIT TIME ESTIMATE | | | DI | DO | AI | AO | ALM A | ALM D | PID | TOTALIZER |
| EST HRS | EST MIN | EQUIPMENT | 5 | 5 | 10 | 10 | 5 | 5 | 30 | 20 |
| 0.25 | 15 | IT-1 AIT | | | 1 | | 4 | 1 | 1 | |
| 0.42 | 25 | IT-2 LS | 1 | | | | | 4 | | |
| 0.58 | 35 | LIT/PIT/DPIT/WIT | | | 1 | | 5 | | | |
| 0 | 0 | | | | | | | | | |
| 0.25 | 15 | FS/PS/DPS | 1 | | | | | 2 | | |
| 0.5 | 30 | FIT/TIT | | | 1 | | | | | 1 |
| 1.67 | 100 | FCV-MOV | 3 | | 1 | 1 | | 3 | 1 | 1 |
| 1 | 60 | CV-MOV | 3 | 2 | | | | 3 | | 1 |
| 1.58 | 95 | PRV-MOV | | 2 | 1 | 1 | | 3 | 1 | 1 |
| 0.42 | 25 | PRV-SOL | | 1 | | | | | | 1 |
| 2.33 | 140 | MT-1 VFD | 5 | 1 | 1 | 1 | 1 | 3 | 1 | 2 |
| 2.67 | 160 | MT-2 VFD SUB | 7 | 1 | 1 | 1 | 1 | 5 | 1 | 2 |
| 1 | 60 | MT-3 ATL | 4 | 1 | | | | 3 | | 1 |
| 1.42 | 85 | MT-4 ATL SUB | 7 | 1 | | | | 5 | | 1 |
| 1.25 | 75 | MT-5 ATL SUB EQ | 6 | 1 | | | | 4 | | 1 |
| 1.08 | 65 | MT-6 SS | 5 | 1 | | | | 3 | | 1 |
| 1.58 | 95 | MT-7 CHEM | 2 | 1 | 1 | 1 | 1 | 1 | 1 | 1 |
| 0.17 | 10 | HT | 1 | | | | | 1 | | |
| 0 | 0 | | | | | | | | | |
| OIT TIME ESTIMATE FOR EACH TYPE WILL BE TO PLACE AND CONFIGURE THE OBJECT FOR HMI | | | | | | | | | | |
| ALM A AND PID SETPOINTS ARE A PART OF THE OIT OBJECT | | | | | | | | | | |
| AO, ALM A, AND ALM D OBJECTS ARE INCLUDED IN THE DIGITAL AND ANALOG OBJECTS | | | | | | | | | | |
| | | | | | | | | | | |
| AB OIT TIME ESTIMATE | | | DI | DO | AI | AO | ALM A | ALM D | PID | TOTALIZER |
| EST HRS | EST MIN | EQUIPMENT | 5 | 5 | 5 | 0 | 0 | 0 | 10 | 5 |
| 0.25 | 15 | AIT | | | 1 | | 4 | 1 | 1 | |
| 0.42 | 25 | LS | 1 | | | | | 4 | | |
| 0.58 | 35 | LIT/PIT/DPIT/WIT | | | 1 | | 5 | | | |
| 0 | 0 | | | | | | | | | |
| 0.25 | 15 | FS/PS/DPS | 1 | | | | | 2 | | |
| 0.5 | 30 | FIT/TIT | | | 1 | | | | | 1 |
| 1.67 | 100 | FCV-MOV | 3 | | 1 | 1 | | 3 | 1 | 1 |
| 1 | 60 | CV-MOV | 3 | 2 | | | | 3 | | 1 |
| 1.58 | 95 | PRV-MOV | | 2 | 1 | 1 | | 3 | 1 | 1 |
| 0.42 | 25 | PRV-SOL | | 1 | | | | | | 1 |
| 2.33 | 140 | MT-1 VFD | 5 | 1 | 1 | 1 | 1 | 3 | 1 | 2 |
| 2.67 | 160 | MT-2 VFD SUB | 7 | 1 | 1 | 1 | 1 | 5 | 1 | 2 |
| 1 | 60 | MT-3 ATL | 4 | 1 | | | | 3 | | 1 |
| 1.42 | 85 | MT-4 ATL SUB | 7 | 1 | | | | 5 | | 1 |
| 1.25 | 75 | MT-5 ATL SUB EQ | 6 | 1 | | | | 4 | | 1 |
| 1.08 | 65 | MT-6 SS | 5 | 1 | | | | 3 | | 1 |
| 1.58 | 95 | MT-7 CHEM | 2 | 1 | 1 | 1 | 1 | 1 | 1 | 1 |
| 0.17 | 10 | HT | 1 | | | | | 1 | | |
| 0 | 0 | | | | | | | | | |
| ALM A AND PID SETPOINTS ARE A PART OF THE OIT OBJECT | | | | | | | | | | |
| AO, ALM A, AND ALM D OBJECTS ARE INCLUDED IN THE DIGITAL AND ANALOG OBJECTS | | | | | | | | | | |
| | | | | | | | | | | |
| HISTORIAN TIME ESTIMATE | | | DI | DO | AI | AO | ALM A | ALM D | PID | TOTALIZER |
| EST HRS | EST MIN | EQUIPMENT | 0 | 0 | 5 | 5 | 0 | 0 | 15 | 5 |
| 1.08 | 65 | AIT | | | 1 | | 4 | 1 | 1 | |
| 0.42 | 25 | LS | 1 | | | | | 4 | | |
| 0.58 | 35 | LIT/PIT/DPIT/WIT | | | 1 | | 5 | | | |
| 0 | 0 | | | | | | | | | |
| 0.25 | 15 | FS/PS/DPS | 1 | | | | | 2 | | |
| 0.5 | 30 | FIT/TIT | | | 1 | | | | | 1 |
| 1.67 | 100 | FCV-MOV | 3 | | 1 | 1 | | 3 | 1 | 1 |
| 1 | 60 | CV-MOV | 3 | 2 | | | | 3 | | 1 |
| 1.58 | 95 | PRV-MOV | | 2 | 1 | 1 | | 3 | 1 | 1 |
| 0.42 | 25 | PRV-SOL | | 1 | | | | | | 1 |
| 2.33 | 140 | MT-1 VFD | 5 | 1 | 1 | 1 | 1 | 3 | 1 | 2 |
| 2.67 | 160 | MT-2 VFD SUB | 7 | 1 | 1 | 1 | 1 | 5 | 1 | 2 |
| 1 | 60 | MT-3 ATL | 4 | 1 | | | | 3 | | 1 |
| 1.42 | 85 | MT-4 ATL SUB | 7 | 1 | | | | 5 | | 1 |
| 1.25 | 75 | MT-5 ATL SUB EQ | 6 | 1 | | | | 4 | | 1 |
| 1.08 | 65 | MT-6 SS | 5 | 1 | | | | 3 | | 1 |
| 1.58 | 95 | MT-7 CHEM | 2 | 1 | 1 | 1 | 1 | 1 | 1 | 1 |
| 0.17 | 10 | HT | 1 | | | | | 1 | | |
| DIGITAL AND ALARMS ARE NOT LOGGED IN HISTORIAN. | | | | | | | | | | |
| | | | | | | | | | | |
| | | | | | | | | | | |
| CEET TIME ESTIMATE | | | DI | DO | AI | AO | ALM A | ALM D | PID | TOTALIZER |
| EST HRS | EST MIN | EQUIPMENT | 2 | 2 | 10 | 10 | 0 | 0 | 0 | 1 |
| 0.17 | 10 | AIT | | | 1 | | 4 | 1 | 1 | |
| 0.03 | 2 | LS | 1 | | | | | 4 | | |
| 0.17 | 10 | LIT/PIT/DPIT/WIT | | | 1 | | 5 | | | |
| 0 | 0 | | | | | | | | | |
| 0.03 | 2 | FS/PS/DPS | 1 | | | | | 2 | | |
| 0.18 | 11 | FIT/TIT | | | 1 | | | | | 1 |
| 0.45 | 27 | FCV-MOV | 3 | | 1 | 1 | | 3 | 1 | 1 |
| 0.18 | 11 | CV-MOV | 3 | 2 | | | | 3 | | 1 |
| 0.42 | 25 | PRV-MOV | | 2 | 1 | 1 | | 3 | 1 | 1 |
| 0.05 | 3 | PRV-SOL | | 1 | | | | | | 1 |
| 0.57 | 34 | MT-1 VFD | 5 | 1 | 1 | 1 | 1 | 3 | 1 | 2 |
| 0.63 | 38 | MT-2 VFD SUB | 7 | 1 | 1 | 1 | 1 | 5 | 1 | 2 |
| 0.18 | 11 | MT-3 ATL | 4 | 1 | | | | 3 | | 1 |
| 0.28 | 17 | MT-4 ATL SUB | 7 | 1 | | | | 5 | | 1 |
| 0.25 | 15 | MT-5 ATL SUB EQ | 6 | 1 | | | | 4 | | 1 |
| 0.22 | 13 | MT-6 SS | 5 | 1 | | | | 3 | | 1 |
| 0.45 | 27 | MT-7 CHEM | 2 | 1 | 1 | 1 | 1 | 1 | 1 | 1 |
| 0.03 | 2 | HT | 1 | | | | | 1 | | |
| ALM A AND ALM D TEST WILL LIKELY HAPPEN DURING ANALOG AND DIGITAL POINT TEST | | | | | | | | | | |
| NO PID TESTING IN CEET. IT WILL BE A PART OF TESTING THE NARRATIVES | | | | | | | | | | |
